Yaskawa SGDV-1R6A11B Sigma-V 200W MECHATROLINK-II Servo Drive 200V
| Place of Origin | USA |
| Brand Name | YASKAWA |
| Model Number | SGDV-1R6A11B |
Product Overview
The Yaskawa SGDV-1R6A11B is a Sigma-V networked SERVOPACK designed for a compatible 200 W rotary servomotor. It uses MECHATROLINK-II digital communication for coordinated motion control. The complete A11B designation should be used when selecting a maintenance replacement.
Main Features
- Designed for a compatible 200 W Sigma-V rotary servomotor.
- MECHATROLINK-II digital motion-network interface.
- Continuous output current of 1.6 A.
- Maximum output current of 6.5 A.
- Single-axis position, speed and torque control.
- Speed frequency response of up to 1.6 kHz.
- Integrated Safe Torque Off function.
- Complete B-suffix configuration for precise replacement identification.
Technical Specifications
| Manufacturer | Yaskawa Electric |
| Series | Sigma-V SGDV |
| Model | SGDV-1R6A11B |
| Compatible Motor Capacity | 200 W |
| Main Circuit Input | Three-Phase 200–230 VAC |
| Control Circuit Input | Single-Phase 200–230 VAC |
| Continuous Output Current | 1.6 A |
| Maximum Output Current | 6.5 A |
| Communication Interface | MECHATROLINK-II |
| Motor Type | Rotary Servomotor |
| Number of Axes | 1 |
| Encoder Feedback | Sigma-V Serial Encoder |
| Speed Frequency Response | 1.6 kHz |
| Safety Function | Integrated STO |
Compatible System and Applications
This SERVOPACK is intended for compatible MECHATROLINK-II controller systems. Typical applications include compact synchronized axes, electronics machinery, inspection equipment, semiconductor production systems, packaging machinery and small automated positioning mechanisms.
Maintenance and Replacement Notes
Verify the complete SGDV-1R6A11B model and any additional suffix before replacement. Confirm that the controller project uses MECHATROLINK-II and check the network address, communication cycle, firmware, parameter settings and termination arrangement.
Confirm the exact motor, serial encoder, holding brake, network cable, power cable and encoder cable. Do not automatically substitute SGDV-1R6A11A, SGDV-1R6A01B or a MECHATROLINK-III model without reviewing configuration differences.
Related Models
Related models include SGDV-1R6A11A, SGDV-R90A11A, SGDV-2R8A11A and SGDV-1R6A01B. The communication code, final designation and extended suffix are important purchasing and compatibility references.
Inquiry and Supply Notes
Please provide the complete nameplate model, motor model, controller type, communication network, firmware details and photographs of the installed connectors. Condition and supplied accessories must be confirmed in the individual quotation.
