Yaskawa SGDH-15AE Sigma-II 1.5kW 200V Three-Phase Servo Drive
| Place of Origin | USA |
| Brand Name | YASKAWA |
| Model Number | SGDH-15AE |
Product Overview
The Yaskawa SGDH-15AE is a Sigma-II series three-phase AC SERVOPACK designed for compatible 200 V servo motors with a rated capacity of up to 1.5 kW. Its position, speed, and torque control capabilities make it suitable for dynamic industrial machinery and precision automation systems.
Main Features
- 1.5 kW applicable servo motor capacity
- Three-phase 200–230 VAC main circuit input
- 11.6 A continuous rated output current
- Position, speed, and torque operating modes
- Analog voltage and pulse train control interfaces
- Sigma-II serial encoder feedback
- Automatic tuning and vibration suppression
- Suitable for higher-load single-axis applications
Technical Specifications
| Model | SGDH-15AE |
| Series | Yaskawa Sigma-II |
| Product Type | AC Servo Drive / SERVOPACK |
| Main Circuit Input | Three-phase 200–230 VAC, 50/60 Hz |
| Applicable Motor Capacity | 1.5 kW |
| Continuous Output Current | 11.6 A |
| Control Modes | Position, speed, and torque |
| Command Interface | Analog voltage and pulse train |
| Encoder Feedback | Sigma-II serial encoder |
| Controlled Axes | One |
| Speed Frequency Response | 400 Hz |
| Integrated STO | Not provided |
Compatible System and Applications
The SGDH-15AE supports selected Yaskawa Sigma-II 200 V servo motors, including compatible SGMPH, SGMGH, SGMSH, and related motor configurations. The complete motor model, rated current, serial encoder, shaft arrangement, and brake option must be checked before connection.
Typical applications include CNC machinery, packaging equipment, printing systems, automated assembly lines, industrial handling equipment, indexing machines, and high-dynamic positioning axes.
Maintenance and Replacement Notes
Confirm that the required product is SGDH-15AE rather than the single-phase SGDH-15AE-S or system-specific SGDH-15AE-S-OY. These models differ in input phase, current rating, suffix, physical configuration, and system compatibility.
Back up the original parameters and inspect the incoming power, grounding, regenerative resistor, motor wiring, encoder cable, brake control, limit inputs, alarm outputs, cooling system, and external safety circuit before commissioning.
Related Models
Related models include SGDH-10AE, SGDH-15AE-S, SGDH-15AE-S-OY, and SGDH-20AE. Differences in input phase, rated current, full suffix, motor matching, and interface configuration must be verified.
Inquiry and Supply Notes
Please provide the complete nameplate, hardware or firmware revision, controller model, controller project, command or communication network, motor model, encoder type, brake requirement, regenerative resistor information, and cable part numbers. Product condition and supplied accessories should be confirmed separately.
