Schneider ELAU VIA1402B22F0000 PacDrive iSH140/20125 Intelligent Servo Module
| Place of Origin | Germany |
| Brand Name | ELUA |
| Model Number | VIA1402B22F0000 |
Product Overview
Schneider ELAU VIA1402B22F0000 is a PacDrive M iSH140 intelligent servo module used in industrial packaging equipment, synchronized servo systems, and legacy PacDrive production machines. Its core model is iSH140/20125, and the full technical model is iSH140/20125/0/0/00/0/10/11/00.
This model is selected for first-batch upload because it combines the high-torque iSH140/20125 core model with shaft seal, IP65 shaft protection, SKM36 multiturn feedback, and holding brake. It is useful for long-tail searches from users who need an exact replacement module for an installed machine.
Main Features
- PacDrive M iSH140 intelligent servo module
- Commercial reference VIA1402B22F0000
- Core model iSH140/20125
- 1.91 kW rated power and 2000 rpm rated speed
- 12.5 Nm standstill torque and 55 Nm peak torque
- Smooth shaft with shaft sealing ring
- IP65 shaft and IP65 housing protection
- SKM36 multiturn SinCos feedback
- With 23 Nm holding brake
Technical Specifications
| Commercial Ref. | VIA1402B22F0000 |
| Core Model | iSH140/20125 |
| Full Technical Model | iSH140/20125/0/0/00/0/10/11/00 |
| Brand | Schneider ELAU |
| Series | PacDrive M iSH140 |
| Product Type | Intelligent Servo Module / Integrated Servo Drive Motor |
| Rated Power | 1.91 kW |
| Rated Speed | 2000 rpm |
| Rated Torque | 9.1 Nm |
| Standstill Torque | 12.5 Nm |
| Peak Torque | 55 Nm |
| Shaft Configuration | Smooth shaft |
| Encoder | SKM36 multiturn SinCos |
| Holding Brake | With 23 Nm holding brake |
| Protection | IP65 shaft / IP65 housing |
| Connection | Hybrid connector |
| Electrical System | 270–680 VDC bus; integrated servo electronics; 24 VDC control |
| Approx. Weight | 18.5 kg |
| Shaft Diameter | 24 mm |
| Shaft Extension | 50 mm |
| Overall Length | 347 mm |
Compatible System and Applications
VIA1402B22F0000 is used in Schneider ELAU PacDrive M servo systems with compatible C200 or C600 motion controllers, distributed servo communication, HMI panels, machine I/O, power supply units, and industrial control networks. Typical applications include packaging lines, cartoning machines, filling systems, wrapping machines, conveyors, indexing mechanisms, and synchronized production equipment.
Maintenance and Replacement Notes
Before replacing VIA1402B22F0000, verify the full commercial reference, smooth shaft design, shaft seal, IP65 shaft protection, SKM36 multiturn feedback, holding brake, cable set, controller project, and machine axis parameters. Similar iSH140/20125 variants with keyed shaft or SKS36 singleturn feedback may not be direct substitutes.
Related Models
Related iSH140/20125 models include VIA1402B22F0000, VIA1402B21F0000, VIA1402B22A0000, VIA1402B21A0000, VIA1402B31F0000, VIA1402B32A0000, VIA1402B12F0000, VIA1402B11F0000, VIA1402B02F0000, and VIA1402B01F0000. These models may differ by shaft type, shaft seal, feedback type, brake option, and protection rating.
Inquiry and Supply Notes
DF Automatic supplies Schneider ELAU VIA1402B22F0000 intelligent servo modules, PacDrive iSH140 modules, iSH100 modules, iSH070 modules, C200 and C600 controllers, power supplies, cables, HMI panels, and industrial automation spare parts for production line maintenance and legacy servo system replacement.
