B&R X20CP1585 1GHz X20 CPU Controller with Ethernet and POWERLINK
| Place of Origin | Germany |
| Brand Name | B&R |
| Model Number | X20CP1585 |
Product Overview
The B&R X20CP1585 is a fanless X20 CPU controller based on a 1.0 GHz Intel Atom processor with an additional I/O processor. It is designed for machine control, coordinated motion, industrial communication and distributed I/O applications.
Main Features
- Intel Atom processor operating at 1.0 GHz.
- 256 MB DDR2 SDRAM working memory.
- Removable CompactFlash program memory.
- Ethernet and POWERLINK V1/V2 communication.
- RS232, two USB ports and X2X Link.
- One modular interface-expansion slot.
- Fanless industrial construction.
Technical Specifications
| Model | X20CP1585 |
| Processor | Intel Atom, 1.0 GHz |
| Working Memory | 256 MB DDR2 SDRAM |
| Program Memory | Removable CompactFlash |
| Interfaces | RS232, Ethernet, POWERLINK, 2 USB, X2X Link |
| Dimensions | 150 x 99 x 85 mm |
| Approximate Weight | 400 g |
Compatible System and Applications
The X20CP1585 is suitable for modular machinery, packaging lines, robotic cells and motion systems using ACOPOS drives and X20 I/O. Actual compatibility depends on the Automation Runtime version, CompactFlash contents and installed communication module.
Maintenance and Replacement Notes
Confirm the hardware revision, Automation Runtime, CompactFlash capacity, application backup, POWERLINK configuration and installed interface module. An empty replacement CPU does not automatically contain the machine program.
Related Models
Related controllers include X20CP1584, X20CP1486, X20CP1381 and X20CP0484.
Inquiry and Supply Notes
Provide the nameplate, CompactFlash information, runtime version and controller-project details before replacement.
