B&R X20CP1381 Compact PLC with Integrated I/O and POWERLINK
| Place of Origin | Germany |
| Brand Name | B&R |
| Model Number | X20CP1381 |
Product Overview
The B&R X20CP1381 is a compact X20 PLC combining processor, communication interfaces and integrated machine I/O. It uses a 200 MHz x86-compatible processor, 128 MB DDR3 SDRAM and 1 GB onboard flash memory.
Main Features
- 200 MHz x86-compatible processor.
- 128 MB DDR3 SDRAM and 1 GB eMMC flash.
- Integrated digital inputs, outputs and mixed channels.
- Two integrated analog inputs.
- Ethernet, POWERLINK, X2X Link and CAN bus.
- RS232 and two USB interfaces.
- Fanless and battery-free design.
Technical Specifications
| Model | X20CP1381 |
| Processor | x86-Compatible, 200 MHz |
| Working Memory | 128 MB DDR3 SDRAM |
| Application Memory | 1 GB eMMC Flash |
| Integrated I/O | 30 Digital I/O Points and 2 Analog Inputs |
| Supply | 24 VDC, -15% / +20% |
| Dimensions | 164 x 99 x 75 mm |
| Approximate Weight | 310 g |
Compatible System and Applications
The X20CP1381 is suitable for compact packaging, assembly, handling and motion applications requiring integrated I/O and multiple industrial communication interfaces.
Maintenance and Replacement Notes
Confirm the complete model, hardware revision, Automation Runtime, integrated I/O wiring, signal configuration, POWERLINK network and CAN termination. X20CP1381-RT is a separate version and must be verified by its complete nameplate.
Related Models
Related controllers include X20CP1381-RT, X20CP1382, X20CP1484 and X20CP1584.
Inquiry and Supply Notes
Provide the controller nameplate, I/O wiring information, runtime version and communication configuration.
