B&R X20CP0484 667MHz Compact-S PLC with Ethernet and POWERLINK
| Place of Origin | Germany |
| Brand Name | B&R |
| Model Number | X20CP0484 |
Product Overview
The B&R X20CP0484 is a compact X20 Compact-S PLC equipped with a 667 MHz ARM Cortex-A9 processor and an integrated I/O processor. It combines onboard storage, industrial networking and controller functionality in a fanless, battery-free design.
Main Features
- ARM Cortex-A9 processor operating at 667 MHz.
- 256 MB DDR3 SDRAM.
- 2 GB onboard eMMC flash memory.
- Ethernet, POWERLINK V2 and X2X Link.
- Two USB interfaces and RS232 communication.
- Fanless and battery-free construction.
Technical Specifications
| Model | X20CP0484 |
| Processor | ARM Cortex-A9, 667 MHz |
| RAM | 256 MB DDR3 SDRAM |
| Application Memory | 2 GB eMMC Flash |
| Interfaces | RS232, Ethernet, POWERLINK V2, 2 USB, X2X Link |
| Protection | IP20 |
Compatible System and Applications
Typical uses include packaging machines, assembly systems, process equipment and compact motion-control installations. The system requires a compatible X20BB5x, X20BB6x or X20BB7x base and an X20PS9600 or X20PS9602 power module.
Maintenance and Replacement Notes
Verify the Automation Runtime version, application backup, base type, interface modules and POWERLINK configuration. Processor and memory differences must be considered when replacing another X20 CPU.
Related Models
Related models include X20CP0482, X20CP0410 and other X20 Compact-S controllers.
Inquiry and Supply Notes
Provide the controller nameplate, runtime revision, base model and machine-project information.
