Yaskawa SGDV-1R6A01A Sigma-V 200W Analog Pulse Servo Drive 200V
| Place of Origin | USA |
| Brand Name | YASKAWA |
| Model Number | SGDV-1R6A01A |
Product Overview
The Yaskawa SGDV-1R6A01A is a Sigma-V series single-axis SERVOPACK designed for controlling a compatible 200 W Yaskawa rotary servomotor. It supports analog voltage and pulse-train commands and is intended for positioning, speed control and torque-control applications in industrial automation equipment.
Main Features
- Designed for a compatible 200 W Yaskawa Sigma-V rotary servomotor.
- Analog voltage and pulse-train command interface.
- Rated output current of 1.6 A.
- High-speed control with a speed frequency response of up to 1.6 kHz.
- Supports Sigma-V serial encoder feedback.
- Integrated Safe Torque Off function implemented through HWBB.
- Suitable for compact positioning axes, indexing systems and automated machinery.
Technical Specifications
| Manufacturer | Yaskawa Electric |
|---|---|
| Series | Sigma-V SGDV |
| Model | SGDV-1R6A01A |
| Compatible Motor Capacity | 200 W |
| Main Circuit Input | Three-Phase 200–230 VAC |
| Control Circuit Input | Single-Phase 200–230 VAC |
| Rated Output Current | 1.6 A |
| Maximum Output Current | 6.5 A |
| Command Interface | Analog Voltage and Pulse Train |
| Motor Type | Rotary Servomotor |
| Number of Axes | 1 |
| Speed Frequency Response | 1.6 kHz |
| Safety Function | STO via HWBB |
Compatible System and Applications
This SERVOPACK is used with a compatible Yaskawa Sigma-V rotary servomotor and suitable Sigma-V serial encoder. Typical applications include compact machine axes, semiconductor equipment, electronic assembly machinery, packaging systems, indexing tables and general positioning equipment.
Maintenance and Replacement Notes
SGDV products belong to a legacy Yaskawa servo platform. Before replacing an existing unit, verify the complete model suffix, nameplate ratings, firmware version, parameter settings and controller project. Confirm the command signal type, motor model, encoder specification, holding brake, regenerative requirements and all power, encoder and I/O cables.
Do not assume that another SGDV model or a newer SGD7S SERVOPACK is directly interchangeable. Differences in command interfaces, wiring, parameters, encoder compatibility and mechanical installation must be reviewed.
Related Models
Related Sigma-V models include SGDV-R90A01A, SGDV-2R8A01A, SGDV-1R6A11A and SGDV-1R6A05A. These models may use different power ratings, communication interfaces or motor feedback configurations and should not be substituted without technical verification.
Inquiry and Supply Notes
Please provide the complete SERVOPACK model, extended suffix, motor model, controller type, communication network and clear nameplate photographs when requesting a quotation. Availability, condition and supplied accessories must be confirmed for each individual offer.
