Yaskawa SGDV-2R8A11A Sigma-V 400W 200V MECHATROLINK-II Servo Drive
| Place of Origin | USA |
| Brand Name | YASKAWA |
| Model Number | SGDV-2R8A11A |
Product Overview
The Yaskawa SGDV-2R8A11A is a Sigma-V series 400 W AC SERVOPACK equipped with a MECHATROLINK-II digital motion network interface. It is designed for synchronized single-axis control of compatible 200 V rotary servo motors within Yaskawa machine controller systems.
This model is not the same as the analog and pulse train SGDV-2R8A01A. The host controller, MECHATROLINK-II command set, network settings, communication cycle, station configuration, and controller project must be confirmed before replacement.
Main Features
- 400 W maximum applicable servo motor capacity
- Three-phase 200–230 VAC main circuit input
- 2.8 A continuous rated output current
- MECHATROLINK-II digital motion communication
- Single-axis synchronized network control
- 1.6 kHz speed frequency response
- Sigma-V high-resolution serial encoder feedback
- Integrated Safe Torque Off through HWBB
- Automatic tuning and vibration suppression
Technical Specifications
| Model | SGDV-2R8A11A |
| Series | Yaskawa Sigma-V |
| Product Type | Single-Axis Network Servo Drive / SERVOPACK |
| Main Circuit Input | Three-phase 200–230 VAC, 50/60 Hz |
| Control Circuit Input | Single-phase 200–230 VAC, 50/60 Hz |
| Maximum Applicable Motor Capacity | 400 W |
| Continuous Output Current | 2.8 A |
| Maximum Output Current | 9.3 A |
| Control Interface | MECHATROLINK-II |
| Motor Type | Compatible rotary servo motor |
| Encoder Interface | Sigma-V serial encoder |
| Controlled Axes | One |
| Speed Frequency Response | 1.6 kHz |
| Safety Function | Integrated STO through HWBB |
Compatible System and Applications
The SGDV-2R8A11A is intended for compatible Yaskawa Sigma-V 200 V rotary servo motors rated up to 400 W and a host controller that supports the required MECHATROLINK-II communication protocol. Verify the controller generation, transmission cycle, network cable, station address, and command compatibility.
Typical applications include synchronized packaging lines, electronic assembly equipment, semiconductor machinery, multi-axis positioning systems, printing equipment, material handling systems, and automated production machines.
Maintenance and Replacement Notes
Before replacing the SERVOPACK, record the original parameters, network station settings, MECHATROLINK-II configuration, controller project, firmware revision, and motor information. Confirm the complete SGDV-2R8A11A suffix, encoder type, brake, safety wiring, regenerative circuit, communication cable, motor cable, and feedback cable.
SGDV-2R8A01A uses analog and pulse commands, while SGDV-2R8A21A uses MECHATROLINK-III. Neither should be substituted for SGDV-2R8A11A without corresponding controller, network, cable, and project changes.
Related Models
Related models include SGDV-2R8A11B, SGDV-2R8A11B002000, SGDV-2R8A01A, SGDV-2R8A21A, SGDV-1R6A11A, and SGDV-5R5A11A. Verify the complete suffix, network interface, hardware revision, and installed controller system.
Inquiry and Supply Notes
Please provide the full nameplate, hardware or firmware revision, controller model, controller project, MECHATROLINK-II network information, station settings, motor model, encoder type, brake option, cable part numbers, safety circuit requirements, parameter backup, and existing alarm information. Product condition and included components should be confirmed individually.
