Yaskawa SGDV-1R6A05A Sigma-V 200W Analog Pulse Linear Servo Drive 200V
| Place of Origin | USA |
| Brand Name | YASKAWA |
| Model Number | SGDV-1R6A05A |
Product Overview
The Yaskawa SGDV-1R6A05A is a Sigma-V SERVOPACK configuration intended for compatible linear servomotor applications. It uses analog voltage and pulse-train commands while the 05 interface designation identifies a linear-motor feedback configuration rather than the standard rotary-motor configuration used by SGDV-1R6A01A.
Main Features
- 200 W-class Sigma-V SERVOPACK capacity.
- Designed for a compatible Yaskawa linear servomotor system.
- Analog voltage and pulse-train command interface.
- Continuous output current of 1.6 A.
- Maximum output current of 6.5 A.
- Supports compatible external linear-scale feedback.
- Speed frequency response of up to 1.6 kHz.
- Integrated Safe Torque Off function.
Technical Specifications
| Manufacturer | Yaskawa Electric |
| Series | Sigma-V SGDV |
| Model | SGDV-1R6A05A |
| Capacity Class | 200 W Class |
| Main Circuit Input | Three-Phase 200–230 VAC |
| Control Circuit Input | Single-Phase 200–230 VAC |
| Continuous Output Current | 1.6 A |
| Maximum Output Current | 6.5 A |
| Control Interface | Analog Voltage and Pulse Train |
| Motor Type | Linear Servomotor |
| Number of Axes | 1 |
| Feedback Type | Compatible External Linear Scale |
| Speed Frequency Response | 1.6 kHz |
| Safety Function | Integrated STO |
Compatible System and Applications
The SGDV-1R6A05A is used in compatible linear-motion systems requiring precise direct-drive positioning. Applications can include semiconductor equipment, inspection machinery, precision assembly systems, measuring equipment, compact linear stages and other mechanisms where a linear servomotor replaces a rotary motor and mechanical transmission.
Maintenance and Replacement Notes
The SGDV-1R6A05A must not be treated as equivalent to the rotary-motor SGDV-1R6A01A. Verify the complete suffix, linear motor coil model, linear scale manufacturer and signal type, serial converter or feedback interface, magnetic-pole detection method, firmware and parameter configuration.
Also confirm the controller project, analog or pulse command settings, machine travel limits, brake or holding mechanism, power cable, feedback cable and grounding arrangement. Incorrect scale resolution, polarity or motor-phase configuration can prevent correct operation.
Related Models
Related linear-motor configurations include SGDV-2R8A05A, SGDV-3R8A05A and SGDV-1R6A15A. The SGDV-1R6A01A is a rotary-motor analog and pulse configuration and should not be substituted without a complete system review.
Inquiry and Supply Notes
Please provide the complete SERVOPACK suffix, linear motor model, linear scale details, serial converter model, controller information, firmware and photographs of the existing wiring. Product condition and included connectors or accessories must be confirmed for each offer.
